BL7011 SERIES Air Hose Reel
Product Description:
     High grade steel is formed to precise tolerances.Quite possibly the last hose reel you will ever need to buy. A weather resistant, TGIC polyester powder-coad paint is melted to the steel in a 400°F cure oven.Containing special agents that prevent scratching and marring, this hardand smooth coating will stay attractive for years.Professional quality.No more tangled hoses!All steel construction.Automatic rewind.Extra large reel diameter to prevent walk-up hose binding.4-way roller guides and a guide arm that adjusts for any mounting position including floor,pit and ceiling mounting.

Specifications:
     Industrial grade steel construction
     Hose locks in place during use
     Spring powered auto rewind
     Machined to floor, wall or ceiling
     Corrosion resistant powder coat finish
     Full-flow solid brass swivel joint
     Multi-position release ratchet and spring fully enclosed and lubricated
     Four direction non-snag rollers reduce hose wear

点击放大图片


Model
BL7011-25
BL7011-20
BL7011-15
BL7011-10
Hose material
RUBBER HOSE
RUBBER HOSE RUBBER HOSE RUBBER HOSE
Hose length(FT)
82
65 50 25
Hose I.D
3/8"ID
3/8"ID 3/8"ID 3/8"ID
Air lntet/Outlet
3/8"
3/8" 3/8" 3/8"
Working pressure
300PSI
300PSI 300PSI 300PSI
Outer casing material STEEL
STEEL STEEL STEEL
Packing Dim
52.5×26×56.5cm
470×210×500 52.5×26×56.5cm 52.5×26×56.5cm
N.W./G.W.
18/19KGS
18/19KGS 19/20.5KGS 18/19KGS
Container
950PCS/20FT,1925PCS/40FT
551PCS/20FT,1143PCS/40FT 396PCS/20FT, 792PCS/40FT 396PCS/20FT, 792PCS/40FT
